Technical Specification

Enclosure

Weight 3.75KG(8.27Ib), including 1 battery

Dimensions 324mmWx 324mmHx 183mmD

Display

Screen size 307.3mm(12.1in.) measured diagonally

Screen type TFT LCD, white LED backlight, viewing cone of 60°and optimal viewing distance of 1 meter

Resolution 800 x 600 pixels

Alarms

Categories Patient Status and system status

Priorities Low, medium, high

Notification Audible and visual

Setting Full storage, low battery, sensor off

Alarm volume level 45 to 85 decibels

Alarm system delay <10 seconds

SpO2

Aturation range 1% to 100%

Accuracy 70 -100% (±2%)<70% undefined

Resolution 1%

Display sweep speed 10.00mm/sec

Pulse Rate

Aturation range 25-250bpm

Accuracy ±2 bpm /±2%take maximum

Resolution 1bpm

ECG

Aturation range 25-250bpm

Accuracy ±2 bpm /±2%take maximum

Resolution 1bpm

Lead selection I,II,III,V,AVF,AVL,AVR

Gain selection 0.25,0.5,1,2 and 4(mm/mv),auto

Sweep speed 6.25 mm/s,12.5mm/s, 25mm/s,50mm/s

NIBP

Method Oscillometric

Aturation range 0-300mmHg

Accuracy Based on ANSI/AAMI SP10:1992 and 2002 Standards

Measurement time 30 to 50 seconds typical, 120 seconds maximum

Auto Interval Times 2,3,5,10,30 min or 1,2h

RESP

Aturationrange 0-120rpm

Accuracy ±1rpm

Resolution 1rpm

Temperature

Channel Two

Aturation range 25-45℃

Accuracy ±0.2℃,plus the temperature sensor tolerance

Resolution 0.1℃

ETCO2 (Optional)

Mode Sidestream

Aturation range 0-150mmHg

Accuracy 0-40mmHg ±2 mmHg

41-150mmHg ±10%of reading

Resolution 0.1 mmHg

Flow rate 50ml/min ±10 ml/min

Electrical

Battery Four new lithium batteries with 4400mAh will typically provide 4.5 hours of monitoring with external communication, no audible alarm sound, and at an ambient temperature of 25℃

Type Lithium batteries,  4400mAh, DC 11.1V

Voltage AC 100-240V 50-60Hz, 80VA

Environmental

Operating Temperature 0℃-50℃(32°F to 122°F)

StorageTemperature -40℃-75℃(-40°F to 167°F)

Relative 15% to 95%, noncondensing

Humidity

Altitude -500 to 5000m (-1640 to 16404ft)

Trend

Memory Tabular: Saves a total of 120 hours of data events, saves date and

Time, alarm conditions, measurements

Tabular format One table for all parameters

Configuration

Stand configuration SpO2+ECG+NIBP+RESP+TEMP

Optional Sidestream ETCO2 Module, Double Lithium Batteries, IBP, Trolley, Recorder, Brace, IPMS8600 Central monitoring system
