Safety

•High accuracy: ±2%

•Fast start function against start delay

•Anti-bolus function

•DERS (Drug error reduction system)

•IP Level: IP34

•11 hours battery back-up time

Friendliness

•4.3" colour touch screen

•Intuitive operation system

•Automatic calibration

•Inter-Lockable

Specifications and Functions

Dimension242 * 126* 111

WeightApprox.1.7kg

Display4.3 inch colour touch screen

Syringe sizes2ml,5ml, 10ml,20ml,30ml,50/60ml; Automatic recognition

Flow rate accuracy±2%

Flow rate0.1-1500 ml/h (depending on syringe size, with increment 0.01 ml/h)

VTBI0-9999.99 ml

Dose rate unitsMore than 15 types

Concentration calculateAutomatically

Bolus settingManual bolus Programmable bolus

KVO rate0.1-5.0 ml/h

Infusion modes8 infusion modes

(Rate mode, Time mode, Body-weight mode, TIVA mode, Drug library mode, Ramp up/down mode,Loading-dose mode, Sequence mode)

HandleIncluded

Drug libraryMore than 2000

PurgeYes

DPSYes

TitrationYes

Micro modeYes

Standby modeYes

DERSYes

Screen lockYes

Occlusion levels12 levels

Anti-bolusAutomatically

RecordsMore than 5000 entries

AlarmsVTBI near end, VTBI infused, Pressure high,

Battery nearly empty, Battery empty, No power supply, Reminder alarm, KVO finished, Check syringe, Syringe empty, Standby time expired, System error

Safety

Power supplyAC: 100V-240V, 50/60Hz DC: 12V

Battery lifeStandard: 5.5 hours; Optional: 11 hours (@5ml/h)

Charging time< 5 hours

ClassificationClass I, CF

IP LevelIP34

Interface

lrDAOptional

Data interfaceUSB

WirelessWiFi (optional )

DC inputYes

RS232/

Nurse callSupported
