Safety

• High accuracy: ±5%

• Double air bubble detect

• Double pressure detect

• Anti-bolus function

• DERS (Drug error reduction system)

• IP Level: IP34

• 9 hours battery back-up time

Friendliness

• 4.3" colour touch screen

• Intuitive operation system

• Automatic calibration

• Inter-Lockable

Specifications and Functions

Dimension 199 *126*111

Weight Approx.1.4kg

Display 4.3 inch colour touch screen

Flow rate accuracy ±5%

Flow rate 0.1-1500 ml/h (with increment 0.01 ml/h)

VTBI 0-9999.99 ml

Dose rate units More than 15 types

Concentration calculate Automatically

Bolus setting Manual bolus Programmable bolus

KVO rate 0.1-5.0 ml/h

Infusion modes 8 infusion modes

(Rate mode, Time mode, Body-weight mode, TIVA mode, Drug library mode, Ramp up/down mode,Loading-dose mode, Sequence mode)

Handle Included

Drug library More than 2000

Purge Yes

DPS Yes

Titration Yes

Micro mode Yes

Standby mode Yes

DERS Yes

Screen lock Yes

Occlusion levels 12 levels

Anti-bolus Automatically

Records More than 5000 entries

Alarms VTBI near end, VTBI infused, Pressure high,

Battery nearly empty, Battery empty, No power supply, Reminder alarm, KVO finished, Check syringe, Syringe empty, Standby time expired, System error

Safety

Power supply AC: 100V-240V, 50/60Hz DC: 12V

Battery life Standard:4.5 hours; Optional: 9 hours (@25ml/h)

Charging time < 5 hours

Classification Class I, CF

IP Level IP34

Interface

lrDA Optional

Data interface USB

Wireless WiFi (optional )

DC input Yes

RS232 Supported

Nurse call Supported
