1.3.5 inch LCD screen for clear vision within 5 meters

2.Special designed extension line grip

3.One-button night mode design for patient’s more comfortable rest at night

4.Compatible with different brands of 5,10,20/30,50/60 ml syringes

5.Free stacking of single syringe pumps for easy space stations in ICU, NICU, OT etc

                                     Model

No. Parameters－－

SPA112

Channel Single

Stackable YES

Syringe Size 5,10,20,30,50/60ml

Infusion Modes Rate Mode, Rate-Time, Rate-VTBI ,Time-VTBI, Body Weight

Safety Double CPU to make sure higher standard infusion

Drug Library 20 drug list with drug code display

Accuracy ±2%

Time Preset 00:01~99：59 （Hour：Min）

Volume Range 0~9999.9ml

Flow Rate Step by 0.1 ml/h when Rate <100ml/h, 1ml/h when Rate ≥100ml/h

Flow Rate Range 5ml Syringe   0.1ml/h-150ml/h

10ml Syringe  0.1ml/h-300ml/h

20ml Syringe  0.1ml/h-600ml/h

30ml Syringe  0.1ml/h-900ml/h

50/60ml Syringe  0..1ml/h-1200ml/h

 Purge/Bolus Rate/Top Flow Rate 5ml Syringe        150ml/h

10ml Syringe      300ml/h

20ml Syringe      600ml/h

30ml Syringe      900ml/h

50/60ml Syringe  1200ml/h

Audible & Visible Alarms Auto Seft-Test, Syringe Dislocation, Occlusion, Near End,Syringe Empty, VTBI Completion, Low Battery, Battery Exausted,  Motor Malfunction, Incorrect Syringe Specification, Circuit Malfunction, Master CPU Malfunction, Monitoring CPU Malfunction, Parameters Over Limitation，A.C Disconnection, A.C connection

KVO 0.1-5.0ml/h Adjustable

Occlusion Pressure High: 40 KPa±20KPa

Middle: 60 KPa±20KPa

Low: 100KPa±20KPa

Max Infusion Pressure 120KPa

Battery ≥8 hours

Power Consumption 30VA

Power Supply AC：100-240V，50Hz/60Hz

Battery Lithium battery,11.1/2000mAh

Classification Class I,type CF,IPX4

Dimension 26×21.5×11cm

Weight 2kg

Optional Function Ambulance DC: 12V
